Lenovo ThinkSystem DE6600 Hybrid NVMe 2U24 - CTO only

dostupné pouze jako CTO konfigurace


Lenovo ThinkSystem DE6600F and DE6600H are industry-leading end to end NVMe Storage solutions designed to provide high performance, simplicity, capacity, security, and high availability for midrange to highend block NVMe large segment.
The DE6600F and DE6600H deliver enterprise-class storage management capabilities in performance-optimized systems with a wide choice of host connectivity options, flexible drive configurations, and enhanced data management features. The DE6600F all-flash and DE6600H hybrid arrays deliver superior price for performance with sub-100 microsecond response for your most-demanding enterprise applications. For target markets such as: Artificial Intelligence, Big Data Analysts, Oracle/SQL databases, high-performance computing (HPC) and real-time analytics.
DE6600F and DE6600H models are available in a 2U rack form-factor with 24 small form-factor (2.5-inch SFF) NVMe drives and include two controllers, each with 32 GB or 128 GB system memory for a system total of 64 GB or 256 GB. Host interface cards provide 10/25Gb iSCSI, 16/32Gb FC/NVMe-FC, 100Gb IB/NVMe-RoCE host connections and 12Gb SAS expansions.

The ThinkSystem DE6600F and DE6600H offer the following key features and benefits:
Scalable, high performance mid-range all-flash and hybrid storage with dual active/active controller configurations with 32 GB or 128 GB system memory per controller for high availability and performance.
Faster application response times with support for NVMe over Fabrics.
Improved performance and data protection with Dynamic Disk Pools (DDP) technology, as well as support for traditional RAID 0, 1, 3, 5, 6, and 10.
Flexible storage protocols to match diverse client needs with support for 10/25Gb iSCSI, 16/32Gb FC/NVMe-FC, 100Gb IB/NVMe-RoCE host connectivity.
The dual controller enclosure scales up to 367TB (NVMe).
SAS expansion connectivity to expand scalability and capacity.
12 Gb SAS drive-side connectivity with support for up to 24x 2.5-inch small form factor (SFF) drives in the 2U24 SFF expansion enclosure, up to 12x 3.5-inch large form factor (LFF) drives in the 2U12 LFF expansion enclosure, or up to 60x 3.5-inch LFF drives in the 4U60 LFF expansion enclosure.
For "All-Flash" a maximum scalability to up 120 SFF drives by attaching up to four ThinkSystem DE240S 2U24 SFF expansion enclosures.
For "Hybrid" a maximum scalability to up 444 drives by attaching up to seven ThinkSystem DE600S 4U60 LFF expansion enclosures to satisfy growing needs.
Rich set of standard storage management functions available at no extra cost, including Dynamic Disk Pools, snapshots, volume copy and encryption.
Optional licensed functions, including higher number of drives and snapshots for greater scalability for continuous data availability.
Intuitive, web-based GUI for easy system setup and management.
Designed for 99.9999% availability with redundant hot-swap components, including controllers and I/O modules, power supplies, cooling modules (4U60 LFF enclosures only), proactive maintenance, and non-disruptive firmware upgrades.


LenovoPress - https://lenovopress.lenovo.com/lp1643-thinksystem-de6600f-and-de6600h-storage-arrays
